Product Description
Three-Proof 10.1 Inch 1280X800 IP65 Waterproof 4G Industrial Rugged Android Tablet PC
LYA101K20I is a high-performance embedded integrated touch screen with the industrial core core Micro RK3568 (quad-core A55 main frequency 2.0 Ghz) CPU as the core. The product features a high-resolution 10.1-inch LED LCD display (resolution of 1280 * 800) and a 10-point capacitive touch screen. It supports USB, Ethernet, DI / DO, RS232, RS485, CAN, WIFI, BT interface, etc. It is suitable for industrial automation control, man-machine interface, small and medium-sized medical analyzer and other industry applications. Built-alone 0.8T NPU can be used for lightweight AI applications.
Product Performance
| | Performance | Details |
| System | CPU | RK3568 / Cortex A55 4 core main frequency at 2.0GHZ |
| Operating System | Android11.0/Ubuntu18.04/Linux 4.19 |
| Running memory | 2GB/4GB |
| EMMC | 16GB/32GB/64GB/128GB |
| GPU | Mali-G52 1-Core-2EE |
| Display | Size | 10.1 Inch |
| Resolving power | 1280 * 800 |
| Touch form | Capactive 10 touch |
| Luminance | 300 cd/ m²(Select a 450cd / m² s) |
| Angle of view | Full perspective |
| Material | Material quality | Plastic face frame, metal back cover |
| Way to stall | Flat, outer, embedded |
| Product size | 260 * 178 * 41mm |
| IP protection grade | Industrial grade IP65 dustproof water proof (operating face) |
| Power | Power interface | 3 PIN*2.54mm terminal DC24V provides power supply |
| Power input | 12V-30V(Recommended value 24V) |
| Environmental Characteristics | Working temperature | -10℃ ~ 60℃ |
| Storage temperature | -20℃ ~ 70℃ |
| Operating humidity | 5-90 RH% |
| Serial port | 3 RS232,2 RS232 / RS485 / CAN switch; 6-way TTL serial port (reuse with serial port) |
| Audio interface | 1-way MIC interface |
| Gigabit Ethernet interface | 1-Route 10 / 100 /1000 Mbps Ethernet port |
| HDMI interface | 1 HDMI output, with a maximum resolution of 3840 * 2160 |
| TF | 1-Route TF card interface |
| SIM | 1 Standard drawer-type interface with reserved eSIM interface |
| RTC | 1 Built-in supercapacitor |
| WIFI/BT | 2.4G WIFI / BT4.2 |
| GPS | The GPS function 4G module should be replaced |
| 4G | Expand mini PCIE 4G module |
| GPIO | 4 input and output: 2 optical coupling input, 2 relay dry contact output; |
| USB2.0 | 1 Vertical plug interface USB 2.0,4 horizontal plug interface USB 2.0,1 built-in row pin (USB 2.0) |
| USB3.0 | 1 Vertical USB 3.0 (switch through dial switch) |
Key Features:
-- 10.1" Full HD 1280*800 resolution TFT LCD screen.
-- Integrated with RK3568 / Cortex A55 4 core main frequency at 2.0GHZ
-- 4GB DDR2 RAM.
-- 16GB/32GB/64GB/128GB emmc.
-- 10 Points Capacitance Touch Screen
-- Tempered glass for front panel, rugged and low profile design.
-- Stainless steel front bezel.
-- Wide operational temperature range, -10°C to +60°C.
-- RoHS compliant.
Warranty Instruction
Our company will provide you the following services with this card and invoice (or copy) in accordance with the provisions listed in this warranty card:
- The machine is guaranteed for three years. Free warranty for the first year; Only the cost fee will be charged in the second and third years, and the service fee will be charged after three years
- The warranty period starts from the date of invoice
- Please keep this warranty card and invoice (or copy) properly. You can enjoy warranty service only if you show them together during the period
- During the warranty period, failure occurs due to the following conditions:, We will charge a certain fee at its discretion:
Company introduction
Wuhan Longyu Intelligent Technology Co., Ltd has a strong R & D, production, sales and management team. Relying on independently developed embedded computer software system and hardware platform technology, we have carefully developed a series of products, the main products include: man-machine interface touch screen, industrial tablet computer all-in-one, ARM industrial motherboard, industrial display, etc. We strive to promote the upgrading of China's manufacturing industry, the research and development of products are widely used in intelligent transportation, automation equipment, terminal self-help equipment, industrial control, electric power, military industry, finance, network security, Marine manufacturing, medical instruments, numerical control, instrumentation, scientific research and other industries, with many well-known enterprises at home and abroad to maintain long-term stable cooperation.
